MIL-DTL-29397B(MC)
Classification
Examine
Defects
Major
Minor
A
B
e. Run-offs (see classification
of open seams).
f. Stitch tension:
1. Loose tension resulting in
124
loose seam.
2. Loose tension on raised or
239
edge stitching, resulting in
loosely exposed bobbin or top
thread.
3. Tight tension (stitches
125
break when normal strain is
applied).
NOTE:
Puckering is evidence of tight tension. When puckering
is evident, the inspector shall test seam by exerting
pull in lengthwise direction of seam.
g. Stitches per inch (excluding
labels).
1. Less than minimum
specified:
- one or two stitches.
320
- three stitches.
240
- four or more stitches.
126
NOTE:
To be scored only if condition exists on major portion
of seam.
Seams and
h. Stitch and seam type:
stitching
1. Wrong stitch or seam type.
241
(cont'd)
i. Stitching skipped or broken
(on edge, or raised stitching
when seam is seamed, turned and
stitched):
321
- 1/4 inch or more but not
more than 1/2 inch.
242
- more than 1/2 inch.
Shaded parts
a. On outside:
1. Any shaded part (except
243
ornamental braid).
57
