MIL-DTL-29396B(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
1
Cutting.
(cont'd)
d. Cut the body and collar linings,
shoulder eyelet covers and left front
facing eyelet cover from one piece of
rayon lining material. All other
rayon lining parts may be cut from
ends. When pairs of sleeve linings
are cut from ends, the shade of the
sleeve lining shall match. Cut the
strips for the jacket hanger 1-1/8
inches wide. Cut front eyelet cover
in accordance with the pattern.
e. Cut the sleeve cuffs, outer ply
of collar, shoulder straps and cuff
eyelet facings from one piece of the
material specified in 3.3.2.
f. Cut twill or plain weave,
polyester or polyester blend or
polyester and cotton stays for
armhole and shoulder seams on the
bias 3/4 inch wide and 4 ± 1/4 inches
long. Cut twill or plain weave,
polyester or polyester blend or
polyester and cotton for collar
interlining in accordance with the
patterns furnished. Cut the twill or
plain weave, polyester or polyester
blend or polyester and cotton for
binding the neck edge of the jacket
from interlining on the bias, 3/4
inch wide and approximately 5 inches
long.
g. Cut the cotton buckram for
interlining the collar on the
straight in accordance with the
pattern furnished.
h. Cut the piping material (see
3.3.4) for piping the front and
bottom edges of jackets, lower edge
and end of collar and top edge of
ornamental sleeve cuffs. The piping
shall be cut 5/8 to 3/4 inch wide for
collar and ornamental sleeve cuffs,
and 1 inch wide for bottom and front
edges of jacket.
11
