MIL-DTL-29396B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Stitch the collar extension tab
301
SSc-1
10-14
A
A
1/16 inch from the top, front and
(top &
(silk)
bottom edges and continue the
bottom
stitching at the back of tab to top
edges)
row, forming a 1-3/8 to 1-1/2 inch
OSf-1
wide box stitch.
(front
edge)
SSa-1
(back
edge)
20 Assemble body lining.
Finished appearance. All darts and
joining seams shall finish smooth and
flat without pleats, puckers or
gathers. The seams shall start and
finish evenly.
a. The body lining shall consist of
a front, a side back panel, and
center back panel.
b. Fold the front lining lengthwise
301
OSf-1
10-14
A
A
with notches matching, and stitch
front darts in accordance with marks
as indicated on the patterns. The
line of stitching for the darts shall
be 3/8 inch from the folded edge of
the dart at the bottom tapering to a
flat point at the top end, and
securely backtacked.
c. Position the center back lining
301
SSa-1
10-14
A
A
with back edges even and notches
matching. Seam together from the
upper notches for a distance of
approximately 2 inches, and from that
point seam horizontally to 3/8 inch
from the back edge, and continue
seaming to the bottom end of lining.
d. Position the center back to the
301
SSa-1
10-14
A
A
respective side backs with edges even
and notches matching. Join together
with 3/8 inch seam.
e. Position side back and side front
301
SSa-1
10-14
A
A
face to face with edges even and join
together at the side with 3/4 inch
seam.
20
