MIL-DTL-29396B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
c. Extend the depth of the notches
301
LSq-3
10-14
A
A
to the seam line. Turn back the
(b)
facing and topstitch the facing to
the cuff 1/16 to 1/8 inch from the
raised edge.
d. Mark location for three eyelets
on each cuff for removable buttons.
Make cuffs and eyelet opening.
7
(cont'd)
e. Make 1/8 inch eyelet on each of
Eyelet
22 per
A
A
the marks through both plies.
eyelet
f. Position the cuffs on the facing
301
SSa-1
10-14
A
A
with back edges even and notches
(each
matching, with the right side faced
end)
up. Stitch the ends of the opening
through the facing 1/4 inch from back
raw edges.
g. Position the strip of piping
301
BSm-1
10-14
A
A
material on the outside of sleeve
(a)
cuff and stitch together 1/8 inch
from the upper curved and pointed
edge of cuff.
h. Turn back the cuff and piping,
301
SSa-1
10-14
A
A
working the folded edge of the piping
1/8 inch beyond edge of cuff.
Topstitch the cuff to the piping 3/16
inch from folded edge of piping.
i. Press the cuffs smooth and flat
with a heated pressing iron or
pressing machine.
8
Seam sleeves at forearm.
Finished appearance. The forearm
seam shall finish smooth and flat
without twists, gathers, puckers or
pleats and shall start and finish
evenly.
a. Position the top sleeve with
301
SSbd-1
10-14
A
A
upper forearm edge in line with the
to
notch in the armhole edge of under
SSa-1
sleeve and with the notches in the
lower forearm edge of top and under
sleeve matching. Seam top and under
sleeve together 3/8 inch from forearm
edge of top sleeve, forming a tapered
outlet on the under sleeve.
14
