MIL-DTL-29396B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Fold the upper raw edge of the
Hand
2-3
C
outer collar over the interlining and
(silk)
tack to the twill or plain weave,
polyester or polyester blend.
c. Press the collar smooth and flat
with a heated pressing iron or
pressing machine.
18 Assemble collar.
(cont'd)
d. Position the collar on the vinyl
301
LSa-1
10-14
A
A
cord, with the upper edge of the
(silk)
collar abutted against the cord edge.
Stitch collar to the vinyl cord 1/16
inch from edge of collar. Trim the
ends of the cord even with the ends
of the collar.
e. Lap the upper cord edge of collar
301
SSa-1
10-14
A
A
over the top raw edge of collar
(silk)
lining approximately 1/2 inch with
lining face up. Stitch collar to the
lining along the cord edge adjacent
to the stitching line of the collar.
The collar lining shall extend not
less than 2-1/2 inches beyond the
left end of the collar and 1/2 inch
beyond the right end of the collar
for the extension tab.
f. Turn collar lining at the seam to
the inside of collar and press smooth
and flat with a heated pressing iron
or pressing machine.
19 Make collar extension tab.
Finished appearance. The collar
extension tab shall extend 3/4 to 1
inch beyond the folded edge of the
right end of the collar.
a. Turn the top and bottom edges and
Hand
the end of the collar lining at the
right end of the collar to the inside
of the lining and baste the turned
portion along the top, front and
bottom edges to the body of the
lining, forming the collar extension
tab.
19
