MIL-DTL-29477A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
11 Make waistband and insert labels.
Finished appearance. The waistband
shall finish 1-1/4 ± 1/8 inches wide
and shall be uniform in width. The
label shall be positioned on the
center of back caught in the
waistband seam. The stitching shall
not be through the label printing.
a. Overlap the ends of the elastic
301
LSa-1
10-14
50
50
waistband stabilizer 1/2 inch, and
join the ends of the stabilizer with
a single row of stitching forming a
box stitch.
b. Fold the top edge of the skirt to
301
EFa-1
10-14
50
50
the inside, forming a 1-1/4 inch hem
or
and enclosing the elastic waistband
401
50
70
stabilizer (11.a). Stitch the hem
with a single row of stitching 1/8 to
3/16 inch from the edge forming a
tunnel for the stabilizer. The
combination label shall be caught in
the stitching.
c. Place a single row of stitching
301
SSa-1
10-14
50
50
at the upper back seam catching the
or
stabilizer in the stitching.
401
50
70
12 Clean skirt.
a. All ends of stitching shall be
trimmed and the loose threads removed
from the skirt.
b. Any spots, stains and shade
tickets or markings shall be removed
without injury to the material.
13 Press skirt.
a. The entire skirt shall be pressed
smooth with a heated pressing iron or
pressing machine. Press marks and
gloss shall be removed.
14 Prepare for packing.
a.
Examine skirt.
b. An envelope containing the tape
for the skirt hem shall be attached
to the skirt.
11
