MIL-DTL-29384B(MC)
altered in any way and shall be used only as a guide for cutting
the contractor's working patterns. The contractor's working
patterns shall be identical to the standard patterns. The
standard patterns provide 3/8 inch allowance for joining front
and side front, shoulder, bust dart and back seam and 1/4 inch
allowance for all other seams, with a side outlet according to
the pattern. Standard patterns show size and are marked and
notched for proper cutting, placement and assembly of component
parts.
3.5.1 List of pattern parts. The vests shall be cut from the
specified materials in accordance with the pattern parts as
follows:
ITEM
PATTERN NOMENCLATURE
NO. OF CUT PARTS
Material: Cloth, tropical, wool
1
Front
2
2
Side front
2
3
Front facing
2
Material: Cloth, satin, rayon (lining)
4
Back
4
5
Front
2
6
Side front
2
7
Eyelet opening lining
1
8
Facing lining
1
Material: Cloth, nonwoven fusible
9
Front
2
10
Side front
2
Marker
11
Eyelet
3.6. Construction.
3.6.1 Manufacturing requirements. The vests shall be
manufactured in accordance with the operations and the stitch,
seam and stitching type specified in Table I. The contractor is
not required to follow the exact sequence of the operations as
listed in Table I, but all operations specified shall be used to
manufacture the vests.
6
