MIL-DTL-29394C(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
2
Replacement of damaged parts.
a. Replace at time of cutting any
part of the skirt containing holes or
seriously weakening defects such as
smashes, multiple floats, loose
weakening slubs, etc., expected to
develop into holes, shade bars and
dye streaks or unsightly slubs, etc.
b. Replace any part damaged during
manufacturing process by needle chews
which may develop into a hole,
scissor or knife cuts, tears, holes,
mends or burns in the material.
3
Shade marking.
a. Mark, ticket or bundle all
component parts (see 3.6.4) cut from
one piece of basic material, except
those parts cut from ends, to ensure
uniform shade and size throughout the
skirt. All lining parts shall be
marked, bundled or ticketed to ensure
uniform shade and size throughout the
garment.
b. The use of tickets with any metal
fastening devices or sew-on shade
tickets is prohibited on the lining.
4
Make watch pocket and attach
combination label.
a. The watch pocket shall be made of
one ply of basic material and one ply
of interlining cloth and shall finish
not less than 4 inches wide and 4
inches deep.
b. Position both plies of watch
301
SSa-1
12-14
50
50
pocket face up and with sides and
bottom edges even. Join both plies
together 3/8 inch from raw edges, 1/2
inch down from the top raw edges of
each side.
c. Overedge stitch the raw edges of
503
EFd-1
8-10
70
70
side and bottom of pocket.
or
504
-or-
10
