MIL-DTL-29394C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
13 Attach zipper.
(cont'd)
d. With a 1/4 inch seam, topstitch
301
SSa-1
10-14
50
50
left side of opening to zipper tape.
Position placket flat and continue
stitching across bottom and up right
side forming a 1/4 inch welt on both
sides. Placket and slide fastener
shall be caught across the bottom and
right side stitching of skirt
opening.
14 Join lining to skirt.
a. Join lining to the skirt at the
301
SSa-1
10-12
50
50
waist with a 1/4 inch seam from the
raw edges, with respective seams
matching. The center back opening of
lining shall not overlap the slide
fastener.
15 Attach watch pocket.
a. Position the inside edge of the
polyester/cotton twill side of pocket
to the top raw edge of the right
front of skirt waist. The notch of
the pocket shall be 1 inch in from
the side seam. Join the pocket to
the skirt with a 3/8 inch seam, from
notch to notch forming a 4 inch wide
opening at the top of the waist seam.
Turn the pocket up and base stitch
1/16 inch through twill and front of
skirt catching all plys.
b. Notch and turn pocket to the
Bartack
21-28
0
0
inside and bartack each edge of
per
opening.
bartack
16 Join waistband to skirt with hangers
and labels.
a. Position the waistband on the
outside of the skirt, with notches at
the squared end of waistband even
with the edge of placket and the raw
edge of the waistband even with the
top raw waist edge of skirt and with
the notches at the pointed end of
waist band matching the back folded
edge of skirt at the slide fastener.
14
