MIL-DTL-29394C(MC)
ITEM
PATTERN NOMENCLATURE
NO. OF CUT PARTS
Material:
Basic
1
Front
1
2
Back
2
3
Waistband
1
4
Placket
1
5
Watch pocket (bottom ply)
1
Material:
Lining
6
Front
2
7
Back
2
Material:
Twill, polyester and cotton or fusible
8
Waistband-interlining
1
9
Watch pocket (top ply)
1
3.6. Construction. The skirts shall be manufactured in
accordance with operation requirements as specified in Table I.
The contractor is not required to follow the exact sequence of
operation as listed in Table I, but all operations specified
shall be used to manufacture the skirts.
3.6.1 Stitches, seams, and stitchings. Stitch, seam, and
stitching types specified in Table I shall conform to
FED-STD-751. The minimum and maximum number of stitches per inch
shall be specified in Table I.
3.6.1.1. Thread breaks and ends of seams. The ends of all seams
and stitching produced with 301 stitch type, when not caught in
other seams or stitching, shall be backstitched not less than 1/4
inch. Thread breaks (all stitch types) shall be secured by
stitching back of the break not less than 1/2 inch. Skipped
stitches may be repaired by using 301 stitch type. The ends of a
continuous line of stitching shall be overlapped not less than
1/2 inch. Thread ends of darts shall be trimmed to a length of
1/2 inch. When an automatic dart machine is used, the ends shall
be backstitched not less than three stitches.
3.6.2
Buttonhole. The buttonhole shall be eyelet end, taper bar
type.
The finished cut length of buttonhole shall be 3/4 inch.
3.6.3 Pressing. Pressing as required in Table I shall be
accomplished with a heated pressing iron or machine.
8
