MIL-DTL-29394C(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
12 Make waistband.
(cont'd)
When fusing the interlining to the
waistband, position the interlining
on the inside of waistband with
bottom edges even. Stay stitch is
not required.
c. Overedge stitch the inside raw
503
EFd-1
8-12
70
70
edge of waistband.
or
504
d. Fold the waistband in half
301
SSe-2
10-14
50
50
lengthwise face to face with notches
(a)
matching. Join the two plies
together, at the pointed end, with
3/16 inch seam, starting at the
folded edge.
e. Close the squared end by seaming
301
SSe-2
10-14
50
50
the two plies together 3/16 inch from
(a)
the bottom raw edges, starting
approximately midway between the
notches and the end of the waistband,
then seam straight across the width
of the waistband to close the end.
f. Turn the waistband, forcing out
301
SSe-2
10-14
50
50
the corners and point completely, and
edge stitch 1/16 inch from the seamed
edges at the pointed and squared
ends.
g. Continue to edge stitch along the
301
OSf-2
10-14
50
50
length of the waistband 1/16 inch
from the folded edge.
13 Attach zipper.
a. Overedge stitch both sides and
503
EFd-1
8-12
70
70
bottom of placket piece.
or
504
b. Stitch right side of slide
301
SSa-1
10-14
A
A
fastener to right side of placket
piece with edge of zipper tape 1/4
inch in from edge of placket.
c. Fold under both sides of skirt
opening 3/4 inch, positioning slide
fastener and placket piece in the
proper position.
13
