MIL-DTL-29395B(MC)
ITEM
PATTERN NOMENCLATURE
NO. OF CUT PARTS
Material:
Basic
1
Front
2
2
Back
2
3
Left waistband
1
4
Right waistband
1
5
Left fly
1
6
Right fly placket
1
7
Back pocket bearer
2
8
Back pocket facing
2
9
Back pocket flap
4
Material:
Interlining (fusible)
10
Left fly
1
11
Left waistband
1
12
Right waistband
1
13
Back pocket flap
2
Material:
Lining (cloth, twill)
14
Crotch lining
2
15
Pockets
2
3.6. Construction. The slacks shall be manufactured in
accordance with operation requirements as specified in Table I.
The contractor is not required to follow the exact sequence of
operations as listed in Table I, but all operations specified
shall be used to manufacture the slacks.
3.6.1 Stitches, seams and stitching. Stitch, seam and
stitching types specified in Table I shall conform to
FED-STD-751. Whenever two or more methods for seam or stitching
types are given for the same part of the operation, any one of
them may be used. Where stitch 401 is used, the looper (under
thread) shall be on the inside of the slacks. The minimum and
maximum number of stitches per inch shall be as specified in
Table I.
3.6.1.1. Thread breaks and ends of seams. The ends of all seams
and stitching produced with 301 stitch type, when not caught in
other seams or stitching, shall be backstitched not less than
1/4 inch. Thread breaks (all stitch types) shall be secured by
stitching back of the break not less than 1/2 inch. Skipped
stitches may be repaired by using 301 stitch type. The ends of
a continuous line of stitching shall be overlapped not less than
1/2 inch. Thread ends of darts shall be trimmed to a length of
8
