MIL-DTL-29397B(MC)
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
Cutting.
1
a. Cut jackets in strict accordance
with patterns furnished by the
Government.
b. Cut all materials in the
direction of the warp as indicated by
the directional lines on the pattern.
c. Cut all scarlet wool parts of the
coat from one piece of the basic
material.
d. Cut the strapping for the
shoulder loops from basic material in
the direction of the warp 2-3/4
inches long and of sufficient width
so that the finished loops will be
5/8 ± 1/8 inch wide.
e. Cut the body and collar linings,
shoulder eyelet covers and left front
facing eyelet cover from one piece of
rayon lining material. All other
rayon lining parts may be cut from
ends. When pairs of sleeve linings
are cut from ends, the shade of the
sleeve lining shall match. Cut the
strips for the jacket hanger 1-1/8
inches wide. Cut front eyelet cover
in accordance with the pattern.
f. Cut the sleeve cuffs, outer ply
of collar, shoulder straps and cuff
eyelet facings from one piece of the
material specified in 3.3.2.
g. Cut twill or plain weave,
polyester or polyester blend or
polyester and cotton stays for
armhole and shoulder seams on the
bias 3/4 inch wide and 4 ± 1/4 inches
long. Cut twill or plain weave,
polyester or polyester blend or
polyester and cotton for collar
interlining in accordance with the
patterns furnished. Cut the twill or
plain weave, polyester or polyester
blend or polyester and cotton for
binding the neck edge of the jacket
from interlining on the bias, 3/4
inch wide and approximately 5 inches
long.
11
