MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Fold the upper raw edge of the
Hand
2-3
C
outer collar over the interlining and
(silk)
tack to the twill or plain weave,
polyester or polyester blend.
c. Press the collar smooth and flat
with a heated pressing iron or
pressing machine.
d. Position the collar on the vinyl
301
LSa-1
10-14
A
A
cord, with the upper edge of the
(silk)
collar abutted against the cord edge.
Stitch collar to the vinyl cord 1/16
inch from edge of collar. Trim the
ends of the cord even with the ends
of the collar.
20 Assemble collar.
(cont'd)
e. Position an eyelet cover on the
301
LSa-1
10-14
A
A
underside at each end of the collar,
(silk)
(silk)
with one edge of the cover 3/4 to 7/8
inch from the front end, and the
bottom raw edge of the eyelet cover
1/2 to 5/8 inch from the upper cord
edge. Stitch collar to cover along
the cord edge adjacent to the
stitching line of the collar.
f. Lap the upper cord edge of collar
301
SSa-1
10-14
A
A
over the top raw edge of collar
(silk)
(silk)
lining approximately 1/2 inch with
lining face up. Stitch collar to the
lining and eyelet cover along the
cord edge adjacent to the stitching
line of the collar. The stitching
shall extend from center to center of
eyelet covers. The collar lining
shall extend not less than 2-1/2
inches beyond the left end of the
collar and 1/2 inch beyond the right
end of the collar for the extension
tab.
g. Turn collar lining and eyelet
cover at the seam to the inside of
collar and press smooth and flat with
a heated pressing iron or pressing
machine.
20
