MIL-DTL-82122D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE STCH/IN
NDL
LPR
8
(cont'd)
Seam sleeves at forearm.
b. Stitch the top and under sleeve
301
SSbd-1
10-14
A
A
together with a 3/8 inch seam, from
to
the forearm edge of the top sleeve,
SSa-1
forming a tapered outlet on the under
sleeve.
c. Spread open the seam and press
flat with a heated iron or pressing
machine.
d. Mark the bottom of the sleeve as
indicated by the notch in the pattern
for turnup.
9
Baste wigan reinforcement to sleeve.
a. Position the wigan on the sleeves
with the notches on the ends of the
wigan in line with the turnup notches
on the sleeve.
b. Tack the left and right sleeves
101
4-6
A
to the reinforcement pieces along the
or
forearm seam allowance of the top or
Hand
under sleeve, and along the backarm
or
edges of the top and under sleeve.
301
8-12
A
A
Trim ends of wigan even with backarm
edges of top and under sleeve.
c. Baste sleeve and reinforcement
101
4-6
A
piece together at the mark for the
or
bottom turnup.
Hand
10 Seam sleeve at backarm.
Finished appearance. The backarm
seam shall finish smooth and flat
without twists, gathers, puckers, or
pleats and shall start and finish
evenly.
a. Join the top sleeve to
the under
301
SSa-1
10-14
A
A
sleeve at the backarm with
a 3/8 inch
seam, catching the ends of
the wigan
reinforcement piece in the
stitching.
b. Spread open the backarm sleeve
seam allowance and press smooth and
flat with a heated pressing iron.
15
