MIL-DTL-29478A(MC)
TABLE I.
Manufacturing requirements - Continued.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
1
Cutting.
(cont'd)
e. Cut the body and collar linings,
collar eyelet covers, and left front
facing eyelet cover from one piece of
rayon lining material. All other
rayon lining parts may be cut from
ends. When pairs of sleeve linings
are cut from ends, the shade of the
sleeve lining shall match. Cut the
strips for the coat hanger and for
the lining securing straps 1-1/8
inches wide. Cut front eyelet cover
in accordance with the pattern.
f. Cut the wool material for the
sleeve cuffs, outer ply of collar,
and cuff eyelet facings from one
piece of the material specified in
3.3.2.
g. Cut polyester stays for armhole
and shoulder seams on the bias, 3/4
inch wide and 4 + 1/4 inches long.
Cut polyester for collar interlining
in accordance with the patterns
furnished. Cut the polyester for
binding the neck edge of the coat
front interlining on the bias, 3/4
inch wide and approximately 5 inches
long.
h. Cut the cotton buckram for
interlining the collar on the
straight in accordance with the
pattern furnished.
i. Cut the piping material (see
3.3.4) for piping the front and
bottom edge of the coats, lower edge
and end of collar, top edge of
ornamental sleeve cuffs, and the seam
joining the skirt to the center back
on the straight. The piping shall be
cut 5/8 to 3/4 inch wide for collar
and ornamental sleeve cuffs; 1 inch
wide for the bottom and front edges
of coat, and the seam joining the
skirt to the center back.
12
