MIL-DTL-29478A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
Make shoulder loops.
4
(cont'd)
c. Turn the strap right side out,
with seam line placed in center on
the underside, and press smooth and
flat with a heated pressing iron.
Make coat hanger and lining securing
5
straps.
Finished appearance. The coat hanger
and lining securing straps shall
finish 1/4 to 3/8 inch wide.
a. Fold the 1-1/8 inch wide strip of
301
EFp-1
10-14
A
A
lining material in half lengthwise.
Turn the edges to the inside and seam
1/16 inch from the turned edges.
b. Cut the coat hanger 3-3/4 + 1/4
inches long.
c. Cut the lining securing straps
4-1/2 + 1/4 inches long.
6
Make collar eyelet covers.
Finished appearance. The collar
eyelet covers shall finish 1-3/4 +
1/8 inches wide.
a. Turn under the side edges of the
301
EFa-1
10-14
A
A
collar eyelet covers and stitch 1/8
(each
inch from the folded edges, catching
side
the turned under portions in the
edge)
stitching.
b. Fold each cover in half across
301
SSa-1
10-14
A
A
the width and seam 1/16 inch from the
folded side edges.
7
Make front eyelet cover.
a. Fold front eyelet cover in half
301
SSa-1
10-14
A
A
lengthwise and stitch across the
bottom edge with a 1/4 inch seam.
b. Turn the cover right side out.
Press and crease the folded edge
smooth and flat with a heated
pressing iron.
14
