MIL-DTL-29478A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
9
Make cuffs and eyelet openings.
(cont'd)
f. Position the cuff on the facing
301
SSa-1
10-14
A
A
with back edges even, notches
(each
matching, and with the right side
end)
faced up. Stitch the ends of the
opening through the facing 1/4 inch
from back raw edges.
g. Position the strip of piping
301
BSm-1
10-14
A
A
material on the outside of sleeve
(a)
(silk)
(silk)
cuff and stitch together 1/8 inch
from the upper curved and pointed
edge of cuff.
h. Turn back the cuff and piping,
301
SSa-1
10-14
A
A
working the folded edge of the piping
(silk)
(silk)
1/8 inch beyond edge of cuff. Top
stitch the cuff to the piping 3/16
inch from folded edge of piping.
i. Press the cuffs smooth and flat
with a heated pressing iron or
pressing machine.
10 Seam sleeves at forearm.
Finished appearance. The forearm
seam shall finish smooth and flat
without twists, gathers, puckers, or
pleats and shall start and finish
evenly.
a. Position the top sleeve with
301
SSbd-1
10-14
A
A
upper forearm edge in line with the
to
notch in the armhole edge of the
SSa-1
under sleeve and with the notches in
the lower forearm edge of top and
under sleeve matching. Seam top and
under sleeve together 3/8 inch from
forearm edge of top sleeve, forming a
tapered outlet on the under sleeve.
b. Spread open the seam and press
flat with a heated pressing iron.
16
