MIL-DTL-29478A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
j. Block the armholes on a pressing
block, shrinking the top sleeves.
k. Insert a sleeve pad in the
sleeves in order to prevent creasing,
and press sleeves smooth and flat.
74 Press coat.
(cont'd)
l. Press lower edge of coat smooth,
flat, and even. Remove all
impressions on the side and center
back seam allowances. Press linings
throughout, removing all wrinkles and
creases. Press the front and back
lining pleats smooth and flat.
Remove all gloss marks.
75 Attach buttons.
a. Insert the shank of a 40-line
insignia button through each eyelet
on the right and left fronts and at
the back. Secure each button with a
ring toggle.
b. Insert the shank of a 27-line
insignia button through each eyelet
on the sleeve cuffs and secure each
button with a ring toggle.
3.7. Finished measurements. The finished coat shall conform to
the measurements shown on Table II.
TABLE II.
Finished measurements.
1/
Collar length 5/
Breast 2/
Back length
Size
Sleeve length
3/ (inches)
4/ (inches)
(inches)
(inches)
Extra
36
27-1/4
17
13
Small
40
27-3/4
17
14
Small
44
28-1/4
17
15
Medium
48
28-3/4
17
16
Large
52
29-1/4
17
17
Extra
Large
1/
Tolerance on all measurements + 3/8 inch.
47
