MIL-DTL-29479A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH TYPE
BOB/
NO
OPERATION
TYPE
STCH/IN
NDL
LPR
d. Position the interlining on the
503
EFd-1
8-10
70/2
70/2
left fly facing and overedge stitch
or
the back edge of interlining and
504
facing together.
9
Join side pocket stays.
a. The side pocket stays, with the
301
SSa-1
10-14
50/3
50/3
bottom edge turned up 3/8 inch, shall
be attached to the outseam with a 1/8
inch seam at the raw edge. It may
also be attached in the overedge
operation.
10 Set side pocket bearer and facing.
Finished appearance. The side pocket
bearer and facing shall be properly
positioned and securely sewn with the
stitching of uniform gauge and
without pleats, puckers or other
distortions.
a. The side pocket bearer and
facings shall each be a single ply of
basic material.
b. Position the bearer and facing on
the pocket material in accordance
with notches indicated by marks on
the pattern.
c. Fold under the front raw edge of
301
LSd-1
10-14
50/3
50/3
bearer and facing 1/4 to 3/8 inch and
and
stitch to the pocket 1/8 inch from
LSbj-1
the folded edge. Continue stitching
across the bottom raw edge. A
selvage edge need not be turned.
d. Position the label on the folded
301
SSa-1
10-14
50/3
50/3
edge of right pocket, facing the
wearer, and stitch the label to the
pocket 1/16 to 1/8 inch from the
label edge.
11 Attach side pockets (1/8 top).
Finished appearance. The edges of
the pocket opening shall finish
smooth and flat without distortion.
Pocket openings shall be of uniform
appearance. The bottom front corners
of the pockets shall be backstitched.
Care shall be taken to avoid notching
the pockets on the underside beyond
the width of the side seam outlet.
12
