MIL-DTL-82126D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
Make waistband.
5
(cont'd)
f. Trim the excess material at both
301
SSe-2
12-16
A
A
ends to 1/8 inch from the seams.
(silk)
(silk)
Turn the waistband, forcing out the
corners and point completely, and
edge stitch 1/16 inch from the seamed
edges at the pointed and squared
ends.
g. Continue to edge stitch along the
301
OSf-1
12-16
A
A
length of the waistband 1/16 inch
(silk)
(silk)
from the folded edge.
h. The edge stitching may be
performed continuously with the top
stitching on the outside of the
waistband in operation 19.a.
6
Assemble placket and slide fastener
(see Figure 3).
Finished appearance. The placket
shall be smooth and flat. The folds
of the skirt shall completely cover
the slide fastener when slide
fastener is closed. The stitching
shall not interfere with the
operation of the slider.
a. The side and bottom edges of the
503
EFd-1
8-12
70
70
material for the placket shall be
or
neatly and evenly overedge stitched.
504
b. Form the placket by folding the
101
OSf-1
material lengthwise with the side
edges offset 1/4 inch, and baste the
two plies of material together along
the folded edge or the folded edge
may be pressed.
c. Place the closed slide fastener
on the narrow side of the placket
with the top end of the chain 1/2
inch below the top raw edge of the
placket, and with the center of the
chain 5/8 to 3/4 inch from the folded
edge of placket.
d. Join the right half of the
301
SSe-2
12-16
A
A
fastener to the placket with a single
(silk)
(silk)
row of stitches 3/16 to 1/4 inch from
the chain edge through the tape and
both plies of the placket.
11
