MIL-DTL-82126D(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
15 Pink bottom edge of skirt.
a. The raw edge of the bottom of the
front and back skirt shall be neatly
and evenly pinked with the points of
the pinking 1/8 inch in depth.
NOTE: Care shall be exercised during
the pinking operation to assure that
no seam allowance is reduced by more
than 1/16 inch.
16 Join placket assembly to skirt (see
Figure 3).
a. Open the slide fastener and place
the front half of it on the inside of
the right part of the skirt at the
back opening, with the top end of the
chain positioned 1/2 inch below the
top raw edge and with the edge of the
chain positioned 1/4 to 3/8 inch from
the creased front edge of the back
opening.
b. Join the left half of the slide
301
SSak-1
12-16
A
A
fastener to the skirt with a single
row of stitches through the tape and
left back panel of the skirt. The
row of stitches shall extend from the
top edge of the left back panel to
1/4 to 3/8 inch below the bottom end
of the chain, and shall be uniformly
5/16 inch from the center edge of the
back opening.
c. Close the slide fastener and turn
301
LSah-1
12-16
A
A
the skirt right side out. Position
(silk)
(silk)
the right back part of the skirt on
the placket, holding the right edge
of the opening as close as possible
to the chain of the slide fastener so
that in the finished skirt, the edge
of the opening conceals the zipper
when the skirt is worn. Continue to
topstitch along the folded edge of
the right back opening, 5/16 inch
from the folded edge, across the
bottom through the slide fastener
tape and the placket and up the left
back edge of the opening.
15
