MIL-DTL-82126D(MC)
1/2 inch. When an automatic dart machine is used, the ends shall
be backstitched not less than three stitches.
Buttonhole. The buttonhole shall be eyelet end, taper bar
3.6.2
type.
The finished cut length of buttonhole shall be 3/4 inch.
3.6.3 Pressing. Pressing as required in Table I shall be
accomplished with a heated pressing iron or machine.
3.6.4 Shade marking. The component parts shall be marked to
ensure a uniform shade and size throughout the skirt. Any method
of shade marking may be used except:
a.
Corrosive metal fastening devices.
b.
Sew-on shade tickets.
c.
Adhesive type tickets which show discoloration or leave
traces of paper or adhesive mass to the material upon removal of
the tickets.
TABLE I.
Manufacturing requirements.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
1
Cutting.
a. Cut the skirt in strict
accordance with patterns furnished by
the Government.
b. Cut all materials in the
direction indicated by directional
lines on pattern. The directional
line shall be placed in the warp
direction of the cloth unless
otherwise indicated on the pattern.
c. Cut component parts of skirt from
one piece of basic material, except
placket, and watch pocket which may
be cut from ends.
d. Cut front and back lining parts
of the skirt from one piece of lining
material.
e. Cut braid for skirt hangers in
lengths of 4 ± 1/8 inches. Each
skirt shall be provided with two
hangers.
f. Cut hem tapes not less than 65
inches long.
8
