MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
c. Fold the side fronts lengthwise
301
OSf-1
10-14
A
A
with notches matching. Stitch the
entire length of the dart 3/8 inch
from the lower end and tapering to a
point at the upper end.
d. Position the front and side front
301
SSa-1
10-14
A
A
panel with edges even, and join
together with a 3/8 inch seam.
e. Spread open seams and press
smooth and flat with a heated
pressing iron.
f. Press the waist darts flat on the
dart seam without turning the dart to
the right or left.
27 Join backs.
Finished appearance. The side and
center backs shall be joined without
gathers, puckers or pleats.
27 Join backs.
(cont'd)
a. Position the center backs with
301
SSa-1
10-14
A
A
edges even, and join together with a
5/8 inch seam, from the top to the
bottom edge.
b. Join the left and right side
301
SSa-1
10-14
A
A
backs to the respective center backs
with 3/8 inch seam.
28 Join back and front at sides.
a. Position the side back and side
301
SSa-1
10-14
A
A
fronts face to face with edges even,
and join together at the side with
3/4 inch seam.
b. Spread open side and back seams
and press smooth and flat with a
heated pressing iron.
c. Mark and shape the bottom of
front and back in accordance with the
pattern shaper.
24
