MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
34 Mark fronts for positioning the braid
and buttonholes (see Figure 3).
a. Mark the location of buttonholes
on the outside of the left front.
The top buttonhole (line A) shall be
positioned 1 inch below the upper
piped edge and 5/8 inch from the
front piped edge. The lower
buttonhole (line B) shall be 2-1/4 ±
1/8 inches from bottom piped edge and
5/8 inch from the front piped edge.
The remaining three buttonhole marks
shall be evenly spaced.
34 Mark fronts for positioning the braid
and buttonholes (see Figure 3).
(cont'd)
b. Extend each buttonhole line
towards the back and armhole edge.
(Line B shall be 1 inch shorter than
line A.) The length of the top and
bottom line is determined by the
position of the harp on the first
line, top, which shall be
approximately 1-7/8 inches from the
armhole edge to the center of the
harp. The top line shall be measured
from the front edge of the buttonhole
line to the center of the harp.
Transfer this measurement to the
bottom line and reduce length by 1
inch. Draw a straight line from the
bottom line mark through center of
the harp up to the top line,
establishing line C-D as shown on
Figure 3.
c. Bisect the top line A-C and
bottom line B-D and connect the
bisecting points with a straight line
E-F.
d. Position left front of jacket on
right front, face to face with the
collar notches even and the left
front edge 1 inch back of the right
front edge from the collar notch to
the bottom and armhole and bottom
edges even.
27
