MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
e. Trace the five lines on the right
front to coincide with the lines on
the left front; the lines on the
right front shall extend
approximately 2 to 2-1/4 inches from
the front piped edge. The vertical
lines on the right front shall be
identical to lines C-D-E-F on the
left front.
f. Draw a circle 7/8 ± 1/32 inch in
diameter on each side of the five
horizontal lines, centered to bisect
line E-F and with the edge of each
circle touching the horizontal line
forming a figure 8 design as shown on
Figure 3.
34 Mark fronts for positioning the braid
and buttonholes (see Figure 3).
(cont'd)
g. Position the center of the harp
pattern at the line C-D, with the
upper edge of the pattern positioned
at the bottom side of each horizontal
line. Mark the harp in accordance
with the pattern marker. The bottom
edge of the harp must be not less
than 1/2 inch from the line beneath.
35 Baste braid (see Figure 4).
a. Baste braid by hand along each
Hand
6-8
C
side of the horizontal line and
(silk
around the circle figure 8 design and
black)
around the harp. The braid shall
begin and end at the harp with both
ends of the braid secured and tacked
under the horizontal braid. On the
left front, the braid shall be basted
around the buttonhole line with the
outer edge of the braid 1/4 to 3/8
inch from the piped front edge. (On
the right front, the outside edge of
braid shall stop 1/4 inch from left
eyelet marks.)
28
