MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
29 Seam reinforcement stay to shoulder,
armhole, gorge and neck.
Finished appearance. The
reinforcement stays shall be sewn to
the armhole and shoulder edge of the
front without gathers, puckers or
pleats. The top end of the armhole
stay and lower end of the shoulder
stay shall form a right angle at the
armhole without the stays overlapping
each other.
29 Seam reinforcement stay to shoulder,
armhole, gorge and neck. (cont'd)
a. Seam the 3/4 inch wide stays to
301
SSaa-1
10-14
A
A
the underside of the front along the
shoulder edges and upper front edge
of the armhole, respectively, 1/8
inch from the outer edges. The strip
for the shoulders shall be positioned
approximately 1/2 inch from neck and
armholes respectively. The strip for
the upper edge of armholes shall be
positioned approximately 1/2 inch
from the shoulder. The strip for the
gorge shall be positioned
approximately 1/2 inch from shoulder
seams across center back. The strip
for the neck shall be positioned 1/2
inch from shoulder seams to 1/2 inch
from front collar notches.
30 Mark and dress left front.
a. Mark and dress the left front
edge of jacket, from the top notch to
the bottom notch. The mark line
shall be 1 inch from the upper front
edge to the bottom front edge.
NOTE: The dressing and shaping of
the left front shall be performed in
the sewing room.
31 Tape armholes.
a. Sew the cotton tape to the
301
SSaa-1
10-14
A
A
armhole starting with one end
approximately 1 inch above the notch
in the fronts and continuing along
the lower and back edge of the
armhole to approximately 1 inch from
shoulder edge.
25
