MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. The tape shall be stitched with
slight tension along the lower front
edges of the armholes and shall be
held taut while stitching along the
back edge.
32 Press shoulder blades and armhole
tapes.
a. Press the shoulder blades and the
armhole tape smooth and flat with a
heated pressing iron or suitable type
pressing machine.
33 Stitch piping to jacket.
Finished appearance. The piping
shall be uniformly stitched to the
jacket without twists, puckers or
pleats. The piping shall extend from
the collar notch at top edge of the
right front to the collar notch at
top edge of the left front.
a. Position the 1-1/4 inch wide
301
SSa-1
10-14
A
A
strip of piping material on the
outside of left and right front, with
one edge even with top, front and
bottom edges of jacket. Stitch
piping to jacket 1/8 inch from edge.
The piping shall extend from the
collar notch at the top, along the
left and right front and the bottom
edge of the jacket.
b. Turn the piping to the inside,
301
SSe-2
10-14
A
A
working out the folded edge of piping
(b)
1/8 inch beyond edges of jacket.
Topstitch jacket to the piping 3/16
inch from the folded edge of piping,
catching the turned under portion of
the piping in the stitching.
c. Notch out the excess piping
material at the top and bottom front
corners to eliminate bulkiness. Trim
the inner edge of piping on the left
front only from the upper front down
to approximately 1 to 1-1/2 inches
from bottom edge of front, so that
the piping will not interfere with
front buttonholes.
26
