MIL-DTL-29395B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
20 Join left and right fly to front.
(cont'd)
b. Turn joining seam onto fly
301
LSb-1
12-14
50/3
50/3
assembly and stitch 1/16 inch from
seamed edge, starting at top raw edge
of fly and stitching to the notch.
c. Turn left fly to the inside with
joining seam 1/16 to 1/8 inch back of
folded edge. Press front edge
without damage to the fastener,
forcing out the seams to the edge.
d. Stitch left fly to left front,
301
SSa-1
12-14
50/3
50/3
starting at the top and continuing
with a curve to the bottom notch.
The stitching shall be 1-1/4 ± 1/8
inches from the front edge of the
fly.
e. Position right fly assembly on
301
SSa-1
12-14
50/3
50/3
right front with overedged edges and
top raw edges even. Join right fly
to front with 1/2 inch seam.
f. Press right and left fly flat
with heated pressing iron, with the
seam toward the side seam.
g. Edgestitch 1/16 inch from the
301
LSq-2
12-14
50/3
50/3
front seamed edge, through the slide
(b)
fastener tape and the placket.
21 Join waistband to slacks.
Finished appearance. The waistband
shall be joined without twists,
puckers, pleats or distortions. The
back square ends of the waistband
shall be even with the seat seams.
a. Position the left waistband on
301
SSa-1
12-14
50/3
50/3
the left front, face to face, with
the notch and finished left fly
opening matching. Join together with
a 3/8 inch seam.
b. Position the right waistband on
301
SSa-1
12-14
50/3
50/3
the outside of slacks, face to face,
with square end and folded edge of
placket even. Join together with a
3/8 inch seam.
21
