MIL-DTL-29395B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
15 Make waistband.
Finished appearance. The two piece
waistband shall be constructed with
left and right parts. Each part
shall consist of one ply of basic
material and one ply of interlining.
The left waistband shall have a
pointed front end and the right
waistband shall have a square end.
The center back of the waistbands
shall have square ends.
a. Overedge stitch the inside raw
503
EFd-1
8-10
70/2
70/2
or
edge of left and right waistbands and
interlinings.
504
b. Fold the left waistband in half
301
SSe-2
12-14
50/3
50/3
lengthwise, face to face with ends
(a)
even and notches matching. Join the
plies together at the pointed end
with a 1/4 inch seam, starting at the
notches, forming the pointed end and
stitching up to the folded edge.
Finish the square end of left
waistband with a 1/4 inch seam,
turning up 1/4 inch of raw edge and
seaming across the width of the
waistband through all plies to close
end.
c. Fold the right waistband in half
301
SSe-2
12-14
50/3
50/3
lengthwise face to face with ends
(a)
even. Finish each square end with a
1/4 inch seam, turning up 1/4 inch of
raw edge and seaming across the width
of the waistband through all plies to
close the end.
d. Trim the excess material at each
301
SSe-2
12-14
50/3
50/3
end to 1/8 inch from the seams. Turn
(b)
the right and left waistbands,
forcing out the corners and point
completely. Edgestitch 1/16 inch
from the seamed edges at the pointed
and squared ends.
e. Continue to edgestitch along the
301
OSf-1
12-14
50/3
50/3
length of the waistband 1/16 inch
from the upper folded edge.
18
