MIL-DTL-29396B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Notch the top edge of the
interlining in line with the collar
notch.
c. Remove stitches joining front
edge of twill or plain weave,
polyester or polyester blend or
polyester and cotton to jacket front
interlining, approximately 1/2 inch
back from front and top edge of
fronts.
d. Turn the jacket inside out and
trim the interlining only,
approximately 1/4 inch back from the
front and top edge of fronts.
35 Trim jacket front interlining.
(cont'd)
e. Trim the shoulder edge of the
jacket front interlining to
approximately 3/4 inch from shoulder
at armhole edge of fronts and taper
the trimming to 3/8 inch at the neck.
36 Bind front edge and gorge of
interlining.
Fold twill or plain weave, polyester
301
EFa-3
8-10
A
A
or polyester blend or polyester and
cotton back over the top and front
raw edge of the interlining. Stitch
along the top and front edge with
three rows of stitches 1/4 inch
apart, placing the first row 1/8 inch
from folded front edge and catching
the turned-under portion in the
stitching.
37 Bind top neck edge of interlining.
Finished appearance. The twill or
plain weave, polyester or polyester
blend or polyester and cotton binding
shall be uniformly stitched along the
gorge of the jacket front interlining
from the collar notch to the shoulder
point.
27
