MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
a. Position the sleeve-head pad on
the sleeves with the folded edge of
the pad approximately 1/8 inch back
from the raw edge of the armhole-
sleeve seam, and with one end of the
pad matching the notch in the fronts.
b. Stitch the sleeve-head pad to the
301
SSa-1
4-6
24/4
24/4
sleeve from end to end, through the
armhole-sleeve seam allowance, 1/8
inch from the folded edge of the pad,
catching the front and back linings
and the shoulder pad in the
stitching. Continue stitching the
linings around the remainder of the
armhole, catching the underarm
shields in the stitching and trimming
away the excess material.
c. The underarm shield may be basted
to the armhole prior to stitching.
67 Fell back lining and facing-lining
assembly at shoulders.
a. Fell the back lining and facing-
lining assembly together at the
shoulders, placing the stitching over
the folded edge of back lining and
securing the top end of the chest
pleat and the eyelet cover in the
felling.
68 Fell sleeve lining at armhole.
a. Position the sleeve lining at the
armhole with the back and forearm
seams of the sleeve and sleeve lining
matching.
41
