MIL-DTL-29397B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
b. Make a horizontal eyelet end,
Button-
60
B
F
square-bar type buttonhole cut 1-1/4
hole
stitche (silk)
inches long at each of the marks.
s per
button-
hole
c. Securely bartack the end of each
Bartack
21 per
A
A
buttonhole, catching the ends of the
bartack (silk)
gimp and thread in the bartack. Trim
the ends of the gimp and thread.
d. Rebaste the unstitched portion of
the braid around the buttonholes and
complete that portion of the
stitching through all plies (see
Figure 4).
53 Make eyelets in fronts.
Finished appearance. The eyelets
shall be worked with the purling on
the outside of the jacket; and shall
finish with a 1/8 inch diameter
opening. All stitches shall be
securely caught in the fabric.
a. Mark the right front for the
location of five eyelets for
removable insignia buttons to align
with the buttonhole on the left
fronts. The mark for the top eyelet
shall be in line with the right end
of collar and the remaining eyelets
shall be in vertical alignment with
the top mark.
b. Mark location for eyelets on the
right and left front for removable
buttons. The mark for the eyelet
shall be between the braid strands at
the top end of each harp.
c. Make an eyelet at each of the
Eyelet
22 per
A
A
marks through all plies. The eyelet
eyelet
cover on the right front shall not be
caught in the stitching.
54 Press front of jacket.
Finished appearance. Fronts shall
finish smooth and flat without
distortion, with all edges uniformly
worked flat.
36
