MIL-DTL-82125B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
6
Make right front ornamental piece.
Finished appearance. The right front
ornamental piece shall finish smooth
and flat, without twists, gathers,
puckers, pleats, or raw edges.
a. The ornamental piece shall be
made of two pieces of basic material.
b. Stitch the two pieces together
301
SSa-1
10-14
A
A
with a 3/8 inch seam from end to end.
c. Spread open the seam and press
flat with a heated pressing iron.
d. Fold the ornamental piece in half
301
SSa-1
10-14
A
A
lengthwise to the outside and stitch
across the width at one end 1/8 inch
from the raw edge. Spread open the
seam and turn ornamental piece
completely, working out the point.
e. Turn all raw edges 3/8 inch to
Hand
the inside and baste along the turned
edges, closing the end, forming a
point at the center of the finished
end.
7
Make center pleat in body lining.
a. Position left and right back
301
SSa-1
10-14
A
A
lining with edges even and join
(silk)
(silk)
together at the center with a 3/8
inch seam.
b. Fold the lining in accordance
with notches on pattern to form a 1
inch wide pleat, at center back.
c. Press the pleat smooth and flat
from top to bottom edge of lining
with a heated pressing iron. The
folded edge of the pleat on the
outside of the lining shall be
towards the left side.
8
Join back and front lining at sides.
Finished appearance. The side seams
of the lining shall be carefully
joined without twists, gathers,
puckers, or pleats. Seams shall
start and finish evenly.
11
