MIL-DTL-82125B(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
17 Seam shoulders.
Finished appearance. The shoulder
seams shall be uniformly stitched
without a distorted appearance.
a. Join fronts and back together at
301
SSa-1
10-14
A
A
shoulders with a 3/8 inch seam.
b. Spread open the shoulder seam and
press flat with a heated pressing
iron or pressing machine.
18 Stitch darts in front and back.
Finished appearance. The darts shall
be tapered to a point at each end and
shall finish without gathers,
puckers, or pleats.
a. Fold the front and back parts,
301
SSa-1
10-14
A
A
matching the cut edges of the front
and back darts. Stitch the entire
length of the dart, catching the
shoulder and side seams in the
stitching 3/8 inch from cut edges at
the front and back darts and tapering
to zero at both ends.
b. Spread open the dart seams and
press flat with a heated pressing
iron or pressing machine.
19 Mark cape for bottom turn-up.
a. Mark the cape, including the
center back pleat, 1-1/2 inches from
the bottom edge for the turn-up.
20 Stitch tape to bottom edge.
a. Place the 1/2 inch wide rayon
301
LSa-1
10-14
A
A
tape on the outside of the cape at
the bottom edge, with the lower edge
of the tape extending approximately
1/4 inch beyond the bottom edge of
the cape, and stitch to the fronts
and back 1/16 inch from the upper
edge of the tape catching the center
pleat in the stitching.
16
