MIL-DTL-29478A(MC)
Manufacturing requirements - Continued.
TABLE I.
SEAM/
STCH
STCH
BOB/
NO
OPERATION
TYPE
TYPE
STCH/IN
NDL
LPR
47 Baste front linings to coat.
(cont'd)
b. Baste the front lining to the
Hand
coat, starting at the lower end of
or
the chest pleat, continuing along
301
Hopper
lower edge of armhole approximately 2
inches from the edge and ending at
the side seam. Match side seams of
coat and lining and continue basting
as close as possible to the side seam
and then across the bottom towards
the front approximately 4 inches from
piped bottom edge of coat.
48 Join lining at center back.
Finished appearance. The lining
shall be carefully joined at center
back without gathers, puckers or
pleats. The seam shall start and
finish evenly. The folded edge of
the center pleat, on the outside of
the lining, shall be towards the
right side. The center back seam of
the lining shall be between the fold.
a. Position the back parts of lining
301
SSa-1
10-14
A
A
and join together at the center with
a 3/8 inch seam from top to bottom.
b. Overedge stitch entire back seam
503
EFd-1
6-12
A
A
allowance together.
or
504
49 Baste back lining to coat.
a. Fold the back lining forming
Hand
approximately a 1 inch wide pleat at
or
the center back. Baste the back
301
Hopper
lining to the coat along the center
pleat from the top end to
approximately 4 inches from the
bottom finished edge of coat.
b. Baste back lining to coat
Hand
starting at side seam and continuing
or
approximately 3 inches from the
301
Hopper
armhole and shoulder edges.
35
